Double Compression Medium Duty Cable Gland
Cable Gland
Double Compression Medium Duty Cable Gland
Our Double Compression Medium Duty Cable Glands are designed for secure and reliable cable termination in medium-duty industrial applications. Constructed from high-quality brass and finished with a nickel plating, these glands provide exceptional resistance to corrosion and environmental factors. Suitable for a wide range of cable diameters, they are designed to offer robust sealing and secure fastening, ensuring safety and durability in various environments.
Engineered with a double compression design, these glands provide superior sealing and strain relief, preventing the ingress of dust, moisture, and other contaminants. Their versatile design allows easy installation, making them ideal for diverse industrial applications.
- Application: Suitable for medium-duty cable applications, providing secure and weatherproof protection for armored cables.
- Design Features: The double compression design ensures a secure and robust seal for enhanced safety and stability in medium-duty environments. Constructed from high-quality brass with a nickel-plated finish for enhanced corrosion resistance.
- Material of Construction: High-quality Brass with a Nickel Plated finish, available with natural or Neoprene rubber seals.
| Suitable Cable Dia (mm) From | Suitable Cable Dia (mm) To | A Dia | B Dia mm | C A/F mm | D A/C mm | E Nipple Entry Thread | F Length mm | Product Code |
|---|---|---|---|---|---|---|---|---|
| 6.00 | 9.00 | 1/2‘’ | 9.50 | 17.50 | 20.00 | 1/2‘’ | 25.00 | HDC-3/8’’ |
| 9.00 | 12.00 | 15.50 | 12.00 | 22.00 | 25.00 | 5/8’’ | 24.50 | HDC-1/2’’ |
| 12.00 | 14.00 | 17.00 | 14.50 | 24.00 | 27.00 | 3/4’’ | 25.00 | HDC-5/8’’ |
| 14.00 | 16.00 | 19.00 | 15.00 | 25.50 | 29.00 | 3/4’’ | 25.00 | HDC-3/4’’ |
| 16.00 | 18.00 | 20.50 | 15.00 | 26.50 | 31.00 | 3/4’’ | 24.00 | HDC-7/8’’ |
| 18.00 | 21.50 | 23.50 | 20.50 | 31.00 | 36.00 | 1’’ | 24.00 | HDC-1’’ |
| 21.50 | 26.00 | 27.00 | 24.00 | 35.00 | 40.00 | 1.1/8’’ | 21.50 | HDC-1.1/8’’ |
| 26.00 | 30.00 | 31.50 | 26.00 | 41.00 | 47.00 | 1.1/4’’ | 25.00 | HDC-1.1/4’’ |
| 30.00 | 33.00 | 34.00 | 30.50 | 43.00 | 49.50 | 1.3/8’’ | 25.00 | HDC-1.3/8’’ |
| 33.00 | 36.00 | 37.00 | 32.00 | 46.50 | 53.50 | 1.1/2’’ | 25.00 | HDC-1.1/2’’ |
| 36.00 | 43.00 | 46.50 | 43.00 | 56.00 | 65.00 | 2’’ | 24.50 | HDC-1.3/4’’ |
| 43.00 | 46.00 | 50.50 | 43.50 | 58.50 | 67.50 | 2’’ | 25.00 | HDC-2’’ |
| 46.00 | 53.00 | 55.00 | 50.00 | 65.50 | 75.00 | 2.1/4’’ | 25.00 | HDC-2.1/4’’ |
| 52.00 | 60.00 | 64.00 | 57.00 | 77.50 | 89.00 | 2.1/2’’ | 25.00 | HDC-2.1/2’’ |
| 60.00 | 68.00 | 72.00 | 63.00 | 81.00 | 93.50 | 2.3/4’’ | 25.00 | HDC-2.3/4’’ |
| 65.00 | 72.00 | 76.00 | 68.50 | 87.00 | 100.00 | 3’’ | 25.00 | HDC-3’’ |
| 72.00 | 77.00 | 79.50 | 74.00 | 91.00 | 105.00 | 3.1/4’’ | 25.00 | HDC-3.1/4’’ |
| 77.00 | 86.00 | 89.00 | 77.50 | 102.50 | 118.00 | 3.1/2’’ | 25.00 | HDC-3.1/2’’ |
| 86.00 | 96.00 | 98.00 | 93.00 | 114.00 | 131.00 | 4’’ | 25.00 | HDC-4’’ |
